BTEra Excavator
1 / 5
| Model NO. | Xc870K | Type | Crawler Excavator |
| Usage | Special, Marine, Mining, GM Excavator | Bucket | Grab Shovel |
| Transmission | Hydraulic Transmission | Drive Type | Internal Combustion Drive |
| Bucket Capacity | >1.5m³ | Certification | CE, ISO9001: 2000 |
| Operating Weight | 33800kg | Engine Model | AA-6HK1xqp |
| Output Power | 190.5/2000kw/Rpm | Displacement | 7.79L |
Green, environmental protection, fuel-efficient engine with low noise and high power.
Optimized duct design enhances air flow to the engine, increasing system cooling capabilities.
Two-stage fuel filter and oil-water separator prolong the service life of the engine.
Integrated hydraulic system from world-known brands minimizes energy loss.
| Category | Item | Unit | Parameters |
|---|---|---|---|
| Model | Operating weight | kg | 33800 |
| Bucket capacity | m³ | 1.4-1.6 | |
| Engine | Engine model | / | AA-6HK1XQP |
| Cylinders | / | 6 | |
| Output power | Kw/rpm | 190.5/2000 | |
| Max. torque | N.m/rpm | 872.8/1700 | |
| Performance | Travel speed | km/h | 5.5/3.3 |
| Slewing speed | r/min | 9.7 | |
| Ground pressure | kPa | 66 | |
| Max. traction | kN | 261 | |
| Dimensions | Total length | mm | 11388 |
| Total width | mm | 3190 | |
| Total height | mm | 3515 | |
| Scope | Max. digging height | mm | 10074 |
| Max. digging depth | mm | 6972 | |
| Max. digging radius | mm | 10650 |
The excavator is equipped with a high-performance AA-6HK1XQP engine, delivering an output power of 190.5 kW at 2000 rpm.
Yes. It features a world-class radiator and optimized duct design to ensure the equipment operates normally even in high-temperature environments.
The Xc870K utilizes a green, fuel-efficient engine combined with a two-stage fuel filter and an advanced hydraulic system to minimize energy loss and fuel consumption.
This excavator offers a maximum digging depth of 6972 mm and a maximum digging radius of 10650 mm, providing a wide working scope for various projects.
The machine is fully certified with CE and ISO9001: 2000, meeting international standards for quality and safety.
The standard bucket capacity is 1.4 m³, with optional configurations available up to 1.6 m³ to suit different soil and material types.
